Airband Aviation Radio Receiver DIY Kit, High Sensitivity 118-136MHz AM Receiver, with Band - Pass Filter and AGC Circuit for Aircraft - Tower Communication up to 190KM

Description:This DIY aviation radio receiver kit is dedicated to receiving calls between the aircraft and the tower. With high performance antenna (VHF antenna), calls between various types of aircraft and the tower within 190KM in open space can be received.Features:Adopt band-pass filter, 3355 high-level, NE602 mixer, MC1350 programs in place, can receive 118-136MHz AM signal. Printed directly on the PCB trace inductance, greatly simplifying the assembly. The board has to listen to the AGC circuit to ensure comfort, while avoiding the long squelch noise. 12 V power supply, PCB board size is 9.2 * 7.5cm, which can be placed in 97 * 40 * 120mm aluminum chassis to use.Specifications:Color: GreenMaterial: PCBBoard size: 9.2 * 7.5cmPackage weight: 73gNote:This is a DIY kit, hasn't been assembled yet!Due to the VHF bands have similar propagation - rectilinear propagation of light, but the receiving location accessible from the airport, distance(greater than 25Km's) must be installed VHF antenna contour segment gain antenna; receiving location between the airport large obstructions (including but not limited to tall buildings, mountains, towers) is always around the obstacle, thank you!Package List:1 x Airband Radio Receiver DIY Kit1 x Circuit Diagram

• High-Sensitivity Reception: This airband aviation radio receiver DIY kit captures clear AM signals across the full 118-136MHz aviation band, allowing you to monitor real-time communication between aircraft and control towers up to 190KM away in open areas.
• Advanced Circuit Design: The aviation radio receiver kit features a built-in band-pass filter, NE602 mixer, MC1350 amplifier, and AGC circuit to reduce squelch noise and deliver comfortable, consistent audio during extended listening sessions.
• Ideal for Aviation Enthusiasts: Perfect for hobbyists, student pilots, or airport spotters, this airband radio receiver DIY kit lets you tune into live air traffic control conversations, enhancing your understanding of flight operations and radio protocols.
• Quality PCB Construction: Made with a green printed circuit board measuring 9.2 x 7.5cm, this airband radio receiver kit uses directly printed trace inductance for simplified assembly and reliable performance when installed in a standard 97 x 40 x 120mm aluminum chassis.
• Complete DIY Package: The aviation radio receiver kit includes all necessary components and a detailed circuit diagram for easy self-assembly, powered by a standard 12V supply—ideal for hands-on learners and electronics tinkerers interested in real-world RF applications.
